DSF334SCF
特点
|
Brand |
Variety name |
Harmonic Order |
Passband bandwidth |
Pulsation |
Guaranteed attenuation |
Operating temperature range |
|
JK |
D50003AM |
Fundamental |
±1.5kHz min./3dB |
1dB max. |
60dB min. |
−20〜+70℃ |
|
Model |
Number of poles |
Nominal frequency |
Stopband bandwidth |
Insertion loss |
Terminal impedance |
Packaging Unit |
|
DSF334SAF |
2 |
50.000MHz |
±18kHz max./15dB |
40dB max. |
400Ω//9pF |
2000pcs./reel(φ180) |
