DSF633SDF
特点
|
Brand |
Variety name |
Harmonic Order |
Passband bandwidth |
Pulsation |
Guaranteed attenuation |
Operating temperature range |
|
JK |
D38807GR |
Fundamental |
±3.75kHz min./3dB |
1dB max. |
76dB min. |
−20～+70℃ |
|
Model |
Number of poles |
Nominal frequency |
Stopband bandwidth |
Insertion loss |
Terminal impedance |
Packaging Unit |
|
DSF633SDF |
4 |
38.850 MHz |
±15.0kHz min./35dB |
6dB max. |
710Ω//4pF Cc=12.5pF |
1000pcs./reel(φ180) |
